Uncompromised characterizationof all types of materials at the nanoscale.
Ideal for characterization of materials at low beam energiesfor maximum surface topography.
Excellent imaging of beam-sensitive and non-conductive samples.
Fully automated setup of electron beam– optimal imaging conditions are guaranteed by theIn-Flight Beam Tracing™.
Intuitive live SEMnavigation on the sample at magnification as low as 2× without the need of extra optical navigation camera thanks to theWide Field Optics™design.
Unique In-Beam Multidetectordesign allowing angle and energy selective BSE detection.
Intuitive software modular platformdesigned for effortless operation regardless of users’ skill level.
